siemens plc simatic 6GK7277-1AA10-0AA0 COMPACT SWITCH MODULE CSM 1277

sps programmierung s7 COMPACT SWITCH MODULE CSM 1277 CONNECTION SIMATIC S7-1200 AND UP TO 3 FURTHER IND. ETHERNET USERS WITH 10/100 MBIT/S UNMANAGED SWITCH, 4 RJ45 PORTS, EXT. 24V DC POWER SUPPLY, LED DIAGNOSTICS, S7-1200 MODULE INCL. ELECTRONIC MANUAL ON CD

Transmission rate
Transfer rate / 1 10 Mbit/s
Transfer rate / 2 100 Mbit/s
Interfaces
Number of electrical/optical connections / for network components or terminal equipment / maximum 4
Number of electrical connections
  • for network components and terminal equipment
4
  • for power supply
1
Design of the electrical connection
  • for network components and terminal equipment
RJ45 port
  • for power supply
3-pole terminal block
Supply voltage, current consumption, power loss
Type of voltage / of supply voltage DC
Supply voltage / external 24 V
  • minimum
19.2 V
  • maximum
28.8 V
Product component / fusing at power supply input Yes
Type of fusing / at input for supply voltage 0,5 A / 60 V
Consumed current / maximum 0.07 A
Active power loss / at 24 V / for DC 1.6 W
Permitted ambient conditions
Ambient temperature
  • during operating
0…60 °C
  • during storage
-40…+70 °C
  • during transport
-40…+70 °C
Relative humidity
  • at 25 °C / without condensation / during operating / maximum
95 %
Protection class IP IP20
Design, dimensions and weight
Design SIMATIC S7-1200 device design
Width 45 mm
Height 100 mm
Depth 75 mm
Net weight 0.15 kg
Type of mounting
  • 35 mm DIN rail mounting
Yes
  • wall mounting
Yes
  • S7-300 rail mounting
No
Product properties, functions, components / general
Product function / switch-managed No
Standard
  • for EMC / from FM
FM3611: Class 1, Division 2, Group A, B, C, D / T.., CL.1, Zone 2, GP. IIC, T.. Ta
  • for hazardous zone
EN 600079-15:2005, EN 600079-0:2006, II 3 G Ex nA II T4, KEMA 08 ATEX 0003 X
  • for safety / of CSA and UL
UL 508, CSA C22.2 No. 142
  • for emitted interference
EN 61000-6-4 (Class A)
  • for interference immunity
EN 61000-6-2
Verification of suitability EN 61000-6-2, EN 61000-6-4
  • CE mark
Yes
  • C-Tick
Yes
  • KC approval
No



siemens plc hardware 6ES7297-0AX30-0XA0 BATTERY BOARD BB 1297 F. CPU 12XX

automation plc programming SIMATIC S7-1200, BATTERY BOARD BB 1297 FOR LONG-TERM BACKUP OF THE REALTIME CLOCK; PLUGGABLE IN THE SIGNAL BOARD S7-12XX CPU (FW3.0 AND LATER); BATTERY (CR1025) NOT INCLUDED

Interrupts/diagnostics/status information
Alarms
Alarms Yes
Diagnostic messages
Diagnostic functions Yes
Diagnostics indication LED
for maintenance Yes; The maintenance LED (MAINT) of the PLC signals that the battery needs to be replaced.
Degree and class of protection
IP20 Yes
Standards, approvals, certificates
CE mark Yes
CSA approval Yes
C-TICK Yes
FM approval Yes
Marine approval Yes
Marine approval according to American Bureau of Shipping Yes
Marine approval according to Bureau Veritas Yes
Marine approval according to Det Norske Veritas Yes
Marine approval according to Germanischer Lloyd Yes
Marine approval according to Lloyds Register of Shipping Yes
Climatic and mechanical conditions for storage and transport
Climatic conditions for storage and transport
Free fall
Drop height, max. (in packaging) 0.3 m; five times, in dispatch package
Temperature
Permissible temperature range -40 °C to +70 °C
Air pressure acc. to IEC 60068-2-13
Permissible air pressure 1080 to 660 hPa
Mechanical and climatic conditions during operation
Climatic conditions in operation
Temperature
Min. -20 °C
max. 60 °C
Air pressure acc. to IEC 60068-2-13
Permissible air pressure 1080 to 795 hPa
Mechanics/material
Type of housing (front)
Plastic Yes
Dimensions
Width 38 mm
Height 62 mm
Depth 21 mm
Weights
Weight, approx. 40 g

siemens s7 plcs 6ES7290-6AA30-0XA0 SIMATIC S7-1200, EXPANSION CABLE 2.0M

siemens simatic s7 plc SIMATIC S7-1200, EXPANSION CABLE TWO-ROW ARRANGEMENT FOR SM 12XX, 2.0 M

siemens simatic s7 plc 6EP1332-1SH71 POWER SUPPLY S7-1200 PM1207

plc siemens simatic s7 SIMATIC S7-1200 POWER MODULE PM1207 STABILIZED POWER SUPPLY INPUT: 120/230 V AC OUTPUT: 24 V DC/2.5 A

Technical specifications
Product S7-1200 PM1207
Power supply, type 24 V/2.5 A
Input
Input 1-phase AC
Supply voltage / 1 / at AC / nominal value 120 V
Supply voltage / 2 / at AC / nominal value 230 V
Voltage range
  • Note
Automatic range selection
Input voltage / 1 / at AC 85…132 V
Input voltage / 2 / at AC 176…264 V
Wide-range input No
Overvoltage resistance 2.3 × Vin rated, 1.3 ms
Mains buffering at Iout rated, min. 20 ms
Mains buffering at Vin = 93/187 V
Rated line frequency 50/60 Hz
Rated line range 47…63 Hz
Input current / at nominal level of the input voltage 120 V 1.2 A
Input current / at nominal level of the input voltage 230 V 0.67 A
Switch-on current limiting (+25 °C), max. 13 A
Duration of current limiting / at 25 °C / maximum 3 ms
I²t, max. 0.5 A²·s
Built-in incoming fuse T 3,15 A/250 V (not accessible)
Protection in the mains power input (IEC 898) Recommended miniature circuit breaker: 16 A, characteristic B, or 10 A, characteristic C
Output
Output Controlled, isolated DC voltage
Rated voltage Vout DC 24 V
Total tolerance, static ± 3 %
Static mains compensation, approx. 0.1 %
Static load balancing, approx. 0.2 %
Residual ripple peak-peak, max. 150 mV
Spikes peak-peak, max. (bandwidth: 20 MHz) 240 mV
Product feature / output voltage adjustable No
Output voltage setting -
Status display Green LED for 24 V OK
On/off behavior No overshoot of Vout (soft start)
Startup delay, max. 6 s
  • Note
2 s at 230 V, 6 s at 120 V
Voltage rise, typ. 10 ms
Rated current value Iout rated 2.5 A
Current range 0…2.5 A
delivered active power / typ. 60 W
short-term overload current / at short-circuit during run-up / typical 6 A
Duration of overloading ability for excess current / on short-circuiting during the start-up 100 ms
short-term overload current / at short-circuit during operation / typical 6 A
Duration of overloading ability for excess current / on short-circuiting during the operational phase 100 ms
Parallel switching for enhanced performance Yes
Numbers of parallel switchable units for enhanced performance 2
Efficiency
Efficiency at Vout rated, Iout rated, approx. 83 %
Power loss at Vout rated, Iout rated, approx. 12 W
Closed-loop control
Dynamic mains compensation (Vin rated ±15 %), max. 0.3 %
Dynamic load smoothing (Iout: 50/100/50 %), Uout ± typ. 3 %
Load step setting time 50 to 100%, typ. 5 ms
Load step setting time 100 to 50%, typ. 5 ms
Setting time / maximum 5 ms
Protection and monitoring
Output overvoltage protection < 33 V
Current limitation, typ. 2.65 A
Characteristic feature of the output / short-circuit protected Yes
Short-circuit protection Constant current characteristic
Enduring short circuit current / Effective level / typical 2.7 A
Overload/short-circuit indicator -
Safety
Primary/secondary isolation Yes
Potential separation Safety extra-low output voltage Uout acc. to EN 60950-1 and EN 50178
Protection class Class I
stray current / maximum 3.5 mA
CE mark Yes
UL/CSA approval Yes
UL/cUL (CSA) approval cULus-Listed (UL 508, CSA C22.2 No. 107.1), File E197259; cURus-Recognized (UL 60950-1, CSA C22.2 No. 60950-1) File E151273
Explosion protection ATEX (EX) II 3G Ex nA II T4; cULus (ISA 12.12.01, CSA C22.2 No.213) File E330455
FM approval Class I, Div. 2, Group ABCD, T4
CB approval No
Marine approval GL, ABS, BV, DNV, LRS, NK
Degree of protection (EN 60529) IP20
EMC
Emitted interference EN 55022 Class B
Supply harmonics limitation not applicable
Noise immunity EN 61000-6-2
Operating data
Ambient temperature / in operation 0…60 °C
  • Note
with natural convection
Ambient temperature / on transport -40…+85 °C
Ambient temperature / in storage -40…+85 °C
Humidity class according to EN 60721 Climate class 3K3, no condensation
Mechanics
Connection technology screw-type terminals
Connections / Supply input L, N, PE: 1 screw terminal each for 0.5 … 2.5 mm²
Connections / Output L+, M: 2 screw terminals each for 0.5 … 2.5 mm²
Connections / Auxiliary -
Width / of the housing 70 mm
Height / of the housing 100 mm
Depth / of the housing 75 mm
Installation width 70 mm
Mounting height 140 mm
Weight, approx. 0.3 kg
Product feature / of the housing / housing for side-by-side mounting Yes
Type of mounting / wall mounting Yes
Type of fixing / cap rail mounting Yes
Type of mounting / S7-300 rail mounting No
Installation Snaps onto DIN rail EN 60715 35×7.5/15, wall mounting
Other information Specifications at rated input voltage and ambient temperature +25 °C (unless otherwise specified)

6ES7954-8LF01-0AA0 programmable plc SIMATIC S7 MEMORY CARD, 24 MB

siemens plc controller SIMATIC S7, MEMORY CARD FOR S7-1X00 CPU/SINAMICS, 3,3 V FLASH, 24 MBYTE

6ES7954-8LE01-0AA0 SIMATIC S7 micro plc controllers MEMORY CARD, 12 MB

siemens automation plc SIMATIC S7, MEMORY CARD FOR S7-1X00 CPU/SINAMICS, 3,3 V FLASH, 12 MBYTE

plc and automation 6ES7954-8LB01-0AA0 SIMATIC S7 MEMORY CARD, 2 MB

sps simatic s7, MEMORY CARD FOR S7-1X00 CPU/SINAMICS, 3,3 V FLASH, 2 MBYTE

mini plc siemens software 6ES7 822-0AA01-0YA0 STEP 7 Basic V11

siemens step 7 basic

SIMATIC STEP 7 BASIC V11 SP2 ENGINEERING-SW,FLOATING LICENSE LICENSE KEY ON USB STICK, SW AND DOCU ON DVD, CLASS A, 6 LANGUAGES(GE,EN,IT,FR,SP,CN), EXECUTABLE UNDER WINDOWS XP (32 BIT)/ WINDOWS 7 (32/64 BIT), FOR CONFIGURATION OF SIMATIC S7-1200, SIMATIC BASIC PANELS

plc s7 siemens 6AV6647-0AG11-3AX0 SIMATIC HMI TP1500 BASIC COLOR PN

siemens simatic plc SIMATIC HMI TP1500 BASIC COLOR PN, BASIC PANEL, TOUCH OPERATION, 15″ TFT DISPLAY, 256 COLORS, PROFINET INTERFACE, CONFIGURATION FROM WINCC FLEXIBLE 2008 SP2 COMPACT/ WINCC BASIC V10.5/ STEP7 BASIC V10.5, CONTAINS OPEN SOURCE SW WHICH IS PROVIDED FREE OF CHARGE FOR DETAILS SEE CD

Display
Design of display TFT
Screen diagonal 15 in
Display width 304.1 mm
Display height 228.1 mm
Number of colors 256
Resolution (pixels)
Horizontal image resolution 1024
Vertical image resolution 768
Backlighting
MTBF backlighting (at 25 °C) 50000 h
Dimmable backlight No
Control elements
Keyboard fonts
Number of function keys 0
Keys with LED No
System keys No
Numeric/alphabetical input
Numeric keyboard Yes; Onscreen keyboard
Alphanumeric keyboard Yes; Onscreen keyboard
Touch operation
Design as touch screen Yes
Installation type/mounting
Mounting in portrait format possible No
Mounting in landscape format possible Yes
Supply voltage
Type of supply voltage DC
Rated value (DC) 24 V
permissible range, lower limit (DC) 19.2 V
permissible range, upper limit (DC) 28.8 V
Input current
Current consumption (rated value) 0.8 A
Inrush current A²s 0.2 A²·s
Power
Power consumption, typ. 20 W
Processor
Processor type
X86 No
ARM Yes; RISC 32-bit
Memory
Flash Yes
RAM Yes
Usable memory for user data 2 Mbyte
Type of output
Acoustics
Buzzer Yes
Speaker No
Time of day
Clock
Hardware clock (real-time clock) No
Software clock Yes
Battery-backed No
Synchronizable Yes
Interfaces
Number of RS 485 interfaces 0
Number of USB interfaces 0
Number of SD card slots 0
Number of parallel interfaces 0
Number of 20 mA interfaces (TTY) 0
Number of RS 232 interfaces 0
Number of RS 422 interfaces 0
Number of other interfaces 0
With software interfaces No
Industrial Ethernet
Number of industrial Ethernet interfaces 1
Industrial Ethernet status LED 2
Protocols
PROFINET Yes
Supports protocol for PROFINET IO No
IRT supported No
PROFIBUS No
MPI No
Protocols (Ethernet)
TCP/IP Yes
DHCP Yes
SNMP Yes
DCP Yes
LLDP Yes
WEB characteristics
HTTP No
HTML No
Further protocols
CAN No
MODBUS Yes; Modicon (MODBUS TCP/IP)
Supports protocol for EtherNet/IP Yes
Interrupts/diagnostics/status information
Diagnostic messages
Diagnostic information readable No
Degree and class of protection
IP (at the front) IP65
Enclosure Type 4 at the front Yes
Enclosure type 4x at the front Yes
IP (rear) IP20
Standards, approvals, certificates
CE Yes
KC approval Yes
cULus Yes
C-TICK Yes
GL No
ABS No
BV No
DNV No
LRS No
Class NK No
PRS No
Use in hazardous areas
ATEX Zone 2 No
ATEX Zone 22 No
cULus Class I Zone 1 No
cULus Class I Zone 2, Division 2 No
FM Class I Division 2 No
Ambient conditions
Mounting position vertical
maximum permissible angle of inclination without external ventilation 35 °
Operating temperature
Operation (vertical installation)
in vertical mounting position/ minimum 0 °C
in vertical mounting position/ maximum 50 °C
Operation (max. tilt angle)
at maximum tilt angle/minimum 0 °C
at maximum tilt angle/maximum 40 °C
Storage/transport temperature
Min. -20 °C
max. 60 °C
Relative humidity
max. relative humidity 90 %
Operating systems
Windows CE No
proprietary Yes
other No
Configuration
Message indicator Yes
With alarm logging system (incl. buffer and acknowledgment) Yes
Process value display (output) Yes
Process value default (input) possible Yes
Recipe administration Yes
Configuration software
STEP 7 Basic (TIA Portal) Yes; via integrated WinCC Basic (TIA Portal)
STEP 7 Professional (TIA Portal) Yes; via integrated WinCC Basic (TIA Portal)
WinCC flexible Compact Yes
WinCC flexible Standard Yes
WinCC flexible Advanced Yes
WinCC Basic (TIA Portal) Yes
WinCC Comfort (TIA Portal) Yes
WinCC Advanced (TIA Portal) Yes
WinCC Professional (TIA Portal) Yes
Languages
Online languages
Number of online/runtime languages 5
Languages
Languages per project 32
Languages
D Yes
GB Yes
F Yes
I Yes
E Yes
Chinese traditional Yes
Chinese simplified Yes
DK Yes
FIN Yes
GR Yes
J Yes
KP / ROK Yes
NL Yes
N Yes
PL Yes
P Yes
RUS Yes
S Yes
CZ Yes
SK Yes
TR Yes
H Yes
Functionality under WinCC (TIA Portal)
Libraries Yes
Task planner
time-controlled No
task-controlled Yes
Message system
Number of alarm classes 32
Number of bit messages 200
Number of analog messages 15
System messages HMI Yes
Number of characters per message 80
Number of process values per message 8
Message indicator Yes
Message buffer
Number of entries 256
Circulating buffer Yes
retentive Yes
maintenance-free Yes
Recipe administration
Number of recipes 5
Data records per recipe 20
Entries per data record 20
Size of internal recipe memory 40 kbyte
Recipe memory expandable No
Variables
Number of variables per device 500
Number of variables per screen 30
Limit values Yes
Multiplexing Yes
Structs No
Arrays Yes
Images
Number of configurable images 50
Permanent window/default Yes
Global image Yes
Start screen configurable Yes
Image selection by PLC Yes
Image number in the PLC Yes
Image objects
Number of objects per image 30
Text fields Yes
I/O fields Yes
Graphic I/O fields (graphics list) Yes
Symbolic I/O fields (text list) Yes
Date/time fields Yes
Switches Yes
Buttons Yes
Graphic view Yes
Icons Yes
Geometric objects Yes
Complex image objects
Number of complex objects per screen 5
Alarm view Yes
Trend view Yes
User view Yes
Status/control No
Sm@rtClient view No
Recipe view Yes
f(x) trend view No
System diagnostics view No
Media Player No
Bar graphs Yes
Sliders No
Pointer instruments No
Analog/digital clock No
Lists
Number of text lists per project 150
Number of entries per text list 30
Number of graphics lists per project 100
Number of entries per graphics list 30
Archiving
Number of archives per device 0
Security
Number of user groups 50
Number of user rights 32
Number of users 50
Password export/import No
SIMATIC Logon No
Character sets
Keyboard fonts
US English Yes
Character sets
Tahoma Yes
Arial No
Courier New No
WinCC flexible Standard Yes
Ideographic languages Yes
Font size freely scalable No
Additional character sets can be loaded No
Transfer (upload/download)
MPI/PROFIBUS DP No
USB No
Ethernet Yes
using external storage medium No
Process coupling
S7-1200 Yes
S7-1500 Yes
S7-200 Yes
S7-300/400 Yes
LOGO! Yes
Win AC Yes
SINUMERIK No
SIMOTION No
Allen Bradley (EtherNet/IP) Yes
Allen Bradley (DF1) No
Mitsubishi (MC TCP/IP) Yes
Mitsubishi (FX) No
OMRON (FINS TCP) No
OMRON (LINK/Multilink) No
Modicon (Modbus TCP/IP) Yes
Modicon (Modbus) Yes
Service tools/configuration aids
Clean screen Yes
Touch calibration Yes
Backup/restore Yes
Backup/Restore automatically No
Simulation Yes
Device switchover Yes
Delta transfer No
I/O / Options
I/O devices
Printer No
MultiMediaCard No
SD card No
USB memory No
Mechanics/material
Type of housing (front)
Plastic Yes
Aluminum No
Stainless steel No
Dimensions
Width of the housing front 400 mm
Height of housing front 310 mm
Mounting cutout (W x H x D)
Mounting cutout, width 367 mm
Mounting cutout, height 289 mm
Device depth 60 mm
Weights
Weight without packaging 4.2 kg
Weight incl. packaging 4.68 kg
